2inch~16inch Dredging Floating Pipeline Abrasion Resistance Floating Discharge Pipes

Name: 2inch16inch Dredging Floating Pipeline Abrasion Resistance Floating Discharge Pipes
Brand: Hongruntong Marine
Price: 85 USD

Quality 2inch~16inch Dredging Floating Pipeline Abrasion Resistance Floating Discharge Pipes for sale

Brand Name : Hongruntong Marine

Model Number : HM-FP30

Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS

Place of Origin : China

MOQ : 1

Price : USD85 to USD1050 Per Piece

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 5940 Pieces Per Month

Delivery Time : 5-6 Work Days

Packaging Details : Wooden Pallet, Wooden Case

Productname : Floating Pipeline

Applications : mud,dredge,water suction and discharge etc

Feature : Wear Resistance

Color : Customized Color

Length : Customized Length

Working temperature : -40℃ (-40℉)to 100℃(212℉)

Size : 2inch~16inch

Pressure : 10-21Bar

Contact Now

Dredging Floating Hose

High Abrasion Resistance • Long Service Life • Strong Tensile Strength

Product Overview

The Floating Pipeline is a high-performance offshore slurry transport system engineered for demanding dredging, reclamation, and marine construction projects. Constructed with multi-layer reinforced synthetic carcass materials combined with a high-abrasion resistant rubber inner lining, it ensures long-term durability under continuous hydraulic pressure.

The system integrates a precision-designed buoyancy structure that maintains stable floating alignment across tidal variations and wave impact zones. Unlike conventional rigid pipelines, this system flexes dynamically while maintaining structural integrity, making it ideal for offshore long-distance discharge operations.

Case Study: Qatar Offshore Reclamation Project

In a large-scale offshore reclamation project in Qatar, the engineering team faced severe challenges due to high salinity water, strong tidal currents, and long-distance discharge requirements exceeding 1.5 km. Traditional pipeline systems suffered from frequent misalignment and buoyancy instability.

After deploying the Hongruntong Marine Floating Pipeline system, the entire discharge line remained stable even under continuous wave impact and high-temperature conditions exceeding 40°C. The integrated buoyancy modules ensured uniform floatation along the full pipeline route.

Results included a 32% increase in dredging efficiency, 40% reduction in maintenance interventions, and significant fuel savings for dredging vessels due to improved discharge continuity.

2inch~16inch Dredging Floating Pipeline Abrasion Resistance Floating Discharge Pipes

Technical Specifications

Material	PTFE, Galvanized Steel Wire, PVC Coated Polyester Cloth
Product Name	Floating Pipeline
Inner Wire	Stainless Steel 316
Lining	Polyamide
Carcass	Polyamide fabrics, Polyester films
Outer Wire	Stainless Steel 316
Working Pressure	10 bar to 21 bar
Maximum Length	40 meters
Sample	Available
Delivery Time	Normally 3-5 days

Product Models

Model	Dimensions (mm/in)	Working Pressure (bar/psi)	Safety Factor	Bending Radius (mm)	Weight (kg)	Length (m)
HM-FDH20	20 / 3/4"	16 / 230	6:1	80	0.8	40
HM-FDH25	25 / 1"	16 / 230	6:1	100	1	40
HM-FDH32	32 / 11/4"	16 / 230	6:1	125	1.3	40
HM-FDH40	40 / 11/2"	16 / 230	6:1	140	1.5	40
HM-FDH50	50 / 2"	16 / 230	6:1	180	2.5	40
HM-FDH65	65 / 21/2"	16 / 230	6:1	200	3.3	40
HM-FDH80	80 / 3"	16 / 230	6:1	260	4	40
HM-FDH100	100 / 4"	16 / 230	6:1	380	6.8	40
HM-FDH125	125 / 5"	16 / 230	6:1	440	9.2	40
HM-FDH150	150 / 6"	16 / 230	6:1	500	13.2	40
HM-FDH200	200 / 8"	16 / 230	6:1	750	18	40
HM-FDH250	250 / 10"	16 / 230	6:1	900	26	25

Note: Various sizes can be customized according to requirements.

Key Features

Integrated Engineering Buoyancy System

Fully engineered buoyancy configuration with evenly distributed flotation units ensures consistent hydrostatic balance, preventing uneven sinking and wave-induced instability.

High Performance Abrasion Resistant Inner Layer

Advanced wear-resistant rubber compounds provide exceptional resistance against continuous abrasion from sand, gravel, and high-density sediment mixtures.

Multi Layer Reinforced Structural Strength

Multiple layers of high-strength synthetic fiber reinforcement withstand internal hydraulic pressure and external mechanical forces, ensuring excellent tensile strength.

Marine Environmental Resistance and Stability

Engineered for long-term operation in harsh marine environments, including high salinity seawater, UV exposure, and extreme temperature variations.

Applications

Offshore Dredging and Reclamation Systems: Continuous transport of seabed materials for land reclamation and coastal expansion projects
Port Deepening and Maintenance Engineering: Sediment removal and stable discharge pipelines for navigation channel optimization
River and Estuary Sediment Transport Projects: Stable hydraulic transport of sediments over variable flow conditions

Why Choose Hongruntong Marine

Advanced Marine Pipeline Manufacturing Capability: Specialized production facilities with precision vulcanization technology and automated structural testing
Full Project Customization Engineering Support: Customized solutions including pipeline diameter selection, pressure rating, and buoyancy distribution design
Strict Multi Stage Quality Assurance System: Comprehensive testing including pressure endurance, flotation stability, and abrasion resistance simulation
Proven Global Application Experience: Successful applications in large-scale projects across Middle East, Southeast Asia, and Africa

Frequently Asked Questions

1. What is the maximum operating length of the Floating Pipeline system?
The system can be designed for both short and long-distance dredging operations, with configurations supporting multi-kilometer offshore discharge lines.

2. Can the system operate under strong wave and current conditions?
Yes, the pipeline is engineered with integrated buoyancy and flexible reinforcement to maintain stability under moderate to strong wave and tidal environments.

3. What type of materials can be transported through the pipeline?
Suitable for transporting sand slurry, sediment mixtures, and dredged seabed materials with high abrasion content.

4. How is maintenance managed during long-term operation?
Designed for low maintenance operation requiring only periodic inspection of joints, flotation stability, and surface condition.

5. Is customization available for different dredging projects?
Yes, we provide full customization including diameter, pressure rating, reinforcement structure, and buoyancy configuration.
